Zooz Z-Wave Plus 4-in-1 Sensor ZSE40

Detect, Monitor & Protect

Zooz Valve Control ZAC 03 is equipped with Z-Wave Plus 500 chip


    • 4 different sensors in 1 smart device: motion, light, temperature, and humidity
    • Customize your sensor with 7 levels of motion sensitivity
    • Easy-to-follow LED temperature notifications
    • Security enabled Z-Wave Plus product with AES signal encryption
    • New and improved 500 chip for enhanced wireless communication
    • Capable of advanced home automation when linked with other Z-Wave devices
    • Range of 100 feet (line of sight)
    • Built-in tamper protection
    • Fast and easy installation
    • Sleek, subtle design
    • 1-year warranty

NOTE: Z-Wave gateway controller required - sold separately. You need a security enabled controller to take full advantage of the product.


Temperature, humidity, light, and motion - these are some of the cornerstones that make a home comfortable, efficient, and safe. Now imagine having these things controlled by a single device. Brimming with features, the Z-Wave Plus 4-in-1 Sensor is an efficient solution for solid home protection.
When linked to your Z-Wave gateway controller, monitor and control your home from your mobile device. Receive notifications when the temperature or humidity changes. Be alerted when motion is detected unexpectedly. This sensor has 7 levels of motion sensitivity, allowing you to customize its settings for your specific needs.
The 4-in-1 sensor can even be programmed for advanced home automation when connected to other Z-Wave products - make the temperature decrease when the lights shut off, or link up this sensor with a Z-Wave siren for added smart home security.


Setting up your 4-in-1 sensor is a fast, easy process. Just be sure to connect it to your Z-Wave network before mounting. To include the sensor:

    • Insert the 2 AAA batteries and bring the device as close to your Z-Wave gateway controller as possible
    • Switch your Z-Wave controller into inclusion/pairing mode
    • Press and release the Z-Wave button TWICE quickly
    • The new 4-in-1 sensor will appear on your controller’s device list
    • To disconnect it from your Z-Wave network, simply repeat the steps above but with your Z-Wave controller in exclusion/unpairing mode. Next, take the batteries out and put them back in. The LED indicator should flash 3 times, indicating the device has been successfully excluded.
    • If the LED indicator blinks only once when you re-insert the batteries, please repeat the process above.

To mount the sensor, choose a spot inside your home - at least 7 feet above the ground will yield the best results. With the 2 included screws, attach the mounting bracket to any flat surface - on your basement ceiling, in the corner of your entry hall, wherever you’d like. Once the bracket is secure, slide the 4-in-1 sensor into position and tilt the body in the direction of your choice.

How to mount Zooz ZSE40 Z-Wave Plus 4-in-1 Sensor


NOTE: If you don't see your Z-Wave controller on the list above, please contact us before you purchase this product.


    • Z-Wave Frequency: 908.42 MHz (US)
    • Power: 2 AAA batteries
    • Wireless Range: Up to 100 feet line of sight
    • Operating Temperature: 5° - 104°F
    • Weight: 0.5 oz
    • Dimensions: 2.25" x 2.25" x 1"
    • Installation: Indoor Use Only


Zooz ZSE40 Z-Wave 4-in-1 Sensor Manual (PDF)
